TS 2000-CT | Electronet

Product Description

TS2000-CT Conductivity Transmitter – Switch is a compact and reliable solution for accurate online conductivity measurement in industrial and process applications. It supports conductivity electrodes with cell constants 0.01, 0.1, and 1, covering measurement ranges up to 9999.99 µS/cm. The transmitter provides a stable 4–20 mA analogue output, with optional relay (alarm) output and RS-485 MODBUS RTU communication for seamless system integration. A backlit LCD display ensures clear local indication, while RTD PT-100 temperature compensation improves measurement accuracy. Designed for flexibility, TS2000-CT supports integral or remote sensor mounting with simple installation. Housed in a corrosion-resistant SS-316 enclosure with IP-68 protection, it is ideal for harsh industrial environments and water treatment applications.

Product Parameters

Configure the transmitter and electronics based on application, environment, and compliance requirements.

Type of Input	From Conductivity Electrode
Cell Constant	0.01 / 0.1 / 1
Calibration Range	Factory Calibrated - 1) 0 to 99.99 μS/cm for cell constant 0.01
	0 to 999.99 μS/cm for cell constant 0.1
	0 to 9999.99 μS/cm for cell constant 1
Max. measuring span	9999.99 μS/cm
Min. measuring span	99.99 μS/cm
Power Supply	18-36V DC
Power Consumption	< 5W
Display	Local display LCD with backlit
Type of Output	4-20 mA
Alarm or Relay Output	1 Relay Output (Optional)
Communication Output	RS-485 MODBUS RTU (Optional)
Electronics Transmitter Accuracy	+/- 0.25% F. S.
Response Time	1Sec
Temperature Compensation	RTD PT-100
Isolation	1.4 KV between Input, Output & Power Supply
Sensor Connection	1) Remote 2) Integral
Electrical Connections	M12 Connector
Mounting	2” Pipe Mounting / Direct Line Mounting
Electronic Protection Class	Weather Proof IP-68
Electronics Enclosure	SS-316
Ambient Temperature	20°C to 70°C
Ambient Humidity	5 to 95% non-condensing at 25°C
Flow Through Assembly (Optional)	SS-316 / PP

Need more technical details?

Download the complete product catalogue for detailed specifications, dimensions, certifications, and application guidance.

Download Catalogue Enquire Now

Applications

Electronet instruments are widely deployed across multiple industries and utilities for reliable monitoring and control of critical process parameters.

Industry	Key Applications
Water & Wastewater	Monitoring conductivity/TDS in treatment plants, pipelines, and effluent systems with switch output for alarms or control
Chemical & Petrochemical	Measuring solution concentration and process water quality with switch output for safety/control
Power Generation	Conductivity monitoring in boiler feedwater, cooling water, and condensate systems with switch for process protection
Food & Beverage	Conductivity monitoring in process water, production lines, and tanks with switch output
Pharmaceuticals & Biotechnology	Monitoring conductivity/TDS in bioreactors, storage tanks, and process lines with switch functionality
Pulp & Paper Industry	Monitoring chemical concentrations and water quality in pulping, bleaching, and effluent treatment processes with switch output
Marine & Shipbuilding	Conductivity/TDS measurement in seawater systems, ballast, and cooling circuits with alarm/control functionality
Metals & Mining	Monitoring process water and slurry conductivity for process optimization with switch output
HVAC & Building Automation	Water quality monitoring in cooling towers and chilled water systems with switch functionality
Semiconductor & Electronics	Conductivity/TDS monitoring for ultra-pure water and process control with switch output
