TS 2000-CLT

Product Description

TS 2000 CLT Capacitance Type Level Transmitter – Switch is a robust level measurement solution designed for accurate monitoring of conductive and non-conductive liquids. It features a backlit LCD display with integrated switch functionality for reliable control and indication. The transmitter supports a 4–20 mA output with optional RS-485 MODBUS RTU communication for seamless system integration. Built with an SS-316 enclosure and IP-68 protection, it ensures dependable performance in harsh and wet environments. The device offers multiple probe options and a wide measuring range up to 15,000 mm for versatile applications. Suitable for demanding industrial processes, it delivers stable performance with high accuracy and fast response time.

Product Parameters

Configure the transmitter and electronics based on application, environment, and compliance requirements.

Measuring Range	100 mm to 15000 mm
Probe Type	1 Single Rod (Up to 2000 mm)
	2 Coaxial (Up to 2000 mm)
	3 Rope Type (Above 2000 mm)
Output	4 - 20 mA
Alarm or Relay Output	1 Relay Output (Optional)
Communication Output	RS-485 MODBUS RTU (Optional)
Accuracy	+/- 1% F. S.
Linearity	+/- 1%
Process Temperature	200°C max
Process Pressure	16 kg/cm² max
Probe MOC	PTFE+SS-316
Power Supply	18-36 V DC
Power Consumption	< 5W
Response Time	1 Sec
Temperature Coefficient	+/- 0.01% per °C
MOC Electronics Enclosure	SS-316
Electronic Protection Class	Weather Proof IP-68
Electrical Connection	M12 Connector
Display	Backlight LCD
Process Connection	1" BSP (M)
	1½" BSP (M)
	2" PVC Flanged
	2" SS-316 Flanged
	50 NB SS-316 Tri Clover
Mounting Clamp	Top of the tank

Need more technical details?

Download the complete product catalogue for detailed specifications, dimensions, certifications, and application guidance.

Download Catalogue Enquire Now

Applications

Electronet instruments are widely deployed across multiple industries and utilities for reliable monitoring and control of critical process parameters.

Industry	Key Applications (TS2000-CLT)
Chemical, Process & Pharmaceutical	Continuous level monitoring with high/low limit switching in corrosive acids, chemical batch reactors, solvent staging tanks, and additive dosing vessels.
Fertilizer Industry	Dual continuous readout and safety interlock trip control in aqueous ammonia holding tanks, acid mixing vats, and granulator slurry tanks.
Water & Wastewater Treatment	Continuous level transmission and pump cutoff control in coagulation chemical tanks, lime slurry mixing systems, and treated pure water reservoirs.
Food Industry / Dairy & Milk	Level tracking with overfill alarms in syrup storage tanks, edible oil processing vats, liquid flavor staging vessels, and CIP holding tanks.
Automation & Manufacturing	Combined level measurement and pump protection switching in machine tool coolant tanks, centralized lubrication units, and automated parts cleaning baths.
Steel & Cement Industry	Continuous monitoring and low-level trip switching in mill gear lube oil reservoirs, spray quenching fluid sumps, and utility liquid vessels.
HVAC & FMCG Industry	Chiller expansion tank level management with high-overflow cutoff, cooling tower make-up automation, and liquid formulation buffer tank monitoring.
Infrastructure, Utility & Irrigation	Level telemetry reporting with backup high/low switching in overhead reservoirs, utility distribution balancing sumps, and booster pumping systems.
Mining Industry	Continuous monitoring and limit control in chemical reagent day tanks, flotation additive feeders, and process liquor balancing sumps.
Pulp & Paper Industry	Level indication and interlock switching in chemical sizing tanks, alum holding vessels, retention aid tanks, and bleaching chemical storage.
OEM Equipment Manufacturers	Integrated transmitter-switch unit for packaged boiler feedwater skids, automated dosing packages, fluid dispensing skids, and custom chiller modules.
Sugar & Distillery Industry	Level monitoring and limit alarming in clarified juice receivers, syrup holding vessels, fermentation liquid staging vats, and process wash sumps.
